HOLLAND DB-1245-1

The HOLLAND DB-1245-1 Rigid-Mount, Bolt-On Square Shank Drawbar is designed for trailer and semi-double trailers towing applications. 2.38” and 3” eye I.D. models available.

Technical data





Max. Vertical Load: 8,000 lbs. (3,628 kg)
Max. Gross Trailer Weight: 40,000 lbs. (18,143 kg)
Drawbar Eye Dimensions: 2.38” I.D. with 1.63” diameter section
Weight: 41 lbs. (18.6 kg)



Product information

The HOLLAND DB-1245-1 Bolt-On Square Shank Drawbar is used on straight tongue or hinged tongue trailers and semi-double trailers. For severe off-road applications, reduce published capacities by 25% and use with swivel-mount coupling.

The DB-1245-1 Drawbar features:

  • Forged, heat treated one piece steel
  • Eye I.D. induction hardened for wear resistance
  • 3” Eye I.D. model available (DB-1235-1 & -3)
  • Tested in accordance with SAE J847
  • Black Armour Corrosion Protection
