HOLLAND Dolly Master™

The HOLLAND Dolly Master™ is an economical, tractor nose-mounted device specifically designed for spotting of converter dolly yard spotter applications.

Product information

The Dolly Master™ is an in-cab operated, tractor nose-mounted pin coupling device, featuring a double-acting air cylinder that moves a sliding pin up and down for easy spotting of converter dollies. Model TF-675 lifts from bumper height, and models TF-675-1/3A lift from ground height.

The Dolly Master™ features:

  • Welded steel frame

  • Vertical pin slide with integral guide ramps

  • Optional lock-out cylinder model (TF-675-1)

  • Optional bolt-on model with lock-out sensor (TF-675-3A)

  • Black Armour Corrosion Protection

Technical data
Max. Lift @80 psi: 390 lbs. (177 kg)
Max. Drawbar Pull: 15,000 lbs. (6,800 kg)
Coupling Pin: 1.75” diameter
Weight: 136 - 173 lbs. (61.7 - 78.5 kg) depending on model
Literature
View all
Document Thumbnail
HOLLAND Coupling Products Selection Guide
PDF / 29.17 MB
Document Thumbnail
SAF-HOLLAND Black Armour Sales Brochure
PDF / 792.31 KB
Document Thumbnail
TF-675 Dolly Master Specifications
PDF / 272.78 KB
Document Thumbnail
TF-675-1 Dolly Master Specifications
PDF / 263.03 KB
