HOLLAND EH-3050

The HOLLAND EH-3050 E-Hitch is designed for airport ground support towing and industrial material handling applications. This product is NOT approved for over-the-road towing applications.

Technical data





Max. Vertical Load: 500 lbs. (227 kg)
Max. Drawbar Pull: 30,000 lbs. - 50,000 lbs. (13,610 kg - 22,680 kg)
Drawbar Eye Dimensions: 2.25 - 3.0˝ (57 - 76 mm) I.D. with max. 1.75˝ (44 mm) diameter section
Weight: 21.5 lbs. (9.8 kg)



Product information

The HOLLAND EH-3050 Pin Coupler is designed for airport ground support baggage carts and tow tractors and industrial material handling carts.

The EH-3050 Coupler features:

  • Cast carbon steel construction including frame, pin and handle
  • Heat treated and through hardened pin for wear resistance
  • Interchangeable handle position – fold-down or fixed upright
  • Internally mounted pin spring
  • Galvanized handle and pin
  • Hold open pin position via 1/8 turn
  • Optional auto-lock pin
  • Variable mounting hole pattern
  • Yellow Powder Coat for corrosion protection
