HOLLAND FW2080

The HOLLAND FW2080 Fifth Wheel is a fully oscillating unit, designed to operate on rough and uneven terrain. Engineered for hauling applications where center of gravity of loaded trailer is equal to or below the fifth wheel height. Ideal for heavy haul and lowboy (low-loader) trailers transporting construction equipment. Heavy-duty cast steel top plate construction with integrated oscillating stationary mounting system.

Technical data





D-Value rating D=270kN (3.5” kingpin)
Maximum Vertical Load 70,000 lbs. (32,000 kg)
Maximum Drawbar Pull 200,000 lbs. (91,000 kg)
Kingpin Size 3.5”



Product information

The HOLLAND FW2080 Fifth Wheel Assembly is a heavy-duty fifth wheel designed to provide both front-to-rear and side-to-side oscillation between the tractor and the trailer on rough and uneven terrain.

The FW2080 Fifth Wheel features:

  • Fully oscillating mounting system
  • Infinite lock adjustment
  • 3.5” Kingpin lock
  • Manual secondary lock
  • Forged, machined and heat-treated steel lock jaw
  • Optional air release lock mechanism
  • Optional oscillator lockouts
