HOLLAND FW2800/2900 MOV-ON™

The HOLLAND FW2800 and FW2900 Fifth Wheel with MOV-ON™ Elevating technology for terminal tractor applications was designed to convert a standard road tractor into a low-cost yard spotting application for more efficient yard shuttling by eliminating the need to raise the trailer landing gear.

Product information

The HOLLAND FW2800 and FW2900 Elevating Fifth Wheels are designed to convert a standard road tractor into a low-cost yard spotting application.

The FW2800 and FW2900 Elevating Fifth Wheel features:

  • TwinLock™ mechanism design for unmatched coupling reliability
  • Manual secondary lock
  • In-cab air release
  • Optional single cylinder (50K max lift) or twin cylinder (100K max lift)
  • Optional over-the-road lock down (Single cylinder only)
  • Available lift heights – 14˝, 15˝, 18.5˝ and 19.5˝
Technical data
Maximum Vertical Load 50,000 lbs. (23,000 kg) Single Cylinder
100,000 lbs. (45,000 kg) Twin Cylinder
Kingpin Size  2”
Technologies
MOV-ON Elevating Hydraulic Lift
TwinLock ™ Mechanism Design
Air Release
Literature
View all
Document Thumbnail
HOLLAND Fifth Wheel Rebuild Stand Assembly & Operating Instructions
PDF / 251.84 KB
Document Thumbnail
HOLLAND Fifth Wheel Lock Adjustment Tool Instructions
PDF / 567.48 KB
Interested? Get in contact.
