HOLLAND FW70

The HOLLAND FW70 Fifth Wheel meets the demand for extra capacity loads and operating conditions that require a more robust fifth wheel. The FW70 cast steel top plate is a proven solution for severe-duty vocational on/off highway hauling applications.

Product information

The HOLLAND FW70 Fifth Wheel is a versatile severe-duty fifth wheel built for demanding, extra capacity hauling conditions and is available with multiple mounting configuration options.

The FW70 Fifth Wheel features:

  • Infinite lock adjustment
  • Manual secondary lock
  • Forged, machined and heat-treated steel lock jaw
  • Optional air release lock mechanism
  • Multiple stationary and severe-duty sliding mounting options available
  • Sliding or stationary Kompensator® and No-Tilt systems available
Technical data
Maximum Vertical Load 70,000 lbs. (32,000 kg)
Maximum Drawbar Pull 200,000 lbs. (91,000 kg)
Kingpin Size 2” and optional 3.5”
Technologies
Air Release
KOMPENSATOR® Mounting System
No-Tilt® Mounting System
Literature
View all
Document Thumbnail
Holland Fifth Wheels - TF-TLN-5001 Service Tool Instructions
PDF / 2.68 MB
Document Thumbnail
HOLLAND Fifth Wheel Rebuild Stand Assembly & Operating Instructions
PDF / 251.84 KB
Document Thumbnail
HOLLAND Fifth Wheel Lock Adjustment Tool Instructions
PDF / 567.48 KB
Document Thumbnail
HOLLAND ILS Sliding Fifth Wheel Air Line Kit Flyer
PDF / 372.33 KB
Document Thumbnail
HOLLAND Sliding Fifth Wheels Air Line Kit Instructions
PDF / 231.89 KB
Document Thumbnail
Hollland Fifth Wheel Rebuild Stand Flyer
PDF / 246.36 KB
