HOLLAND MARK V™ Heavy Duty

The HOLLAND MARK V Heavy-Duty Landing Gear takes the rugged design of the standard Mark V model and beefs it up with added features for extreme-duty performance.

Product information

The HOLLAND MARK V Heavy-Duty Landing Gear with its robust design enhancements increases side load capacity by over 45%. Combine with our extra-large, heavy-duty sand shoe for unmatched static load stability.

The MARK V HD Landing Gear features:

  • The industry’s highest side-load capacity rating of 46,000 lbs. (approx. 20,900 kg)

  • Large, robust 5 1/8” square upper leg

  • Large heavy-duty tapered 9-hole mounting plate

  • Reinforced upper leg with ultra-wide tubing collar

  • Fastest to the ground with 2.5 turns per inch

  • Shifts easily in cold weather

  • High-strength ductile iron gears

  • Black Armour® Corrosion Protection

  • Optional Removable Cushion Foot (RCF)

  • Standard 5-Year Warranty and Optional 10-Year NoLube™ Extended Guarantee

  • Large 1 5/8” diameter double lead elevating screw

  • Premium Gearbox Grease service rated for -65ºF (-54°C) to 225ºF (107°C)

Technical data
Lift capacity:  62,500 lbs. (approx. 28,350 kg) at 100 ft.-lbs. (135 Nm) input torque
Ultimate load capacity: 200,000 lbs. (approx. 90,700 kg)
Side-Load Capacity: 46,000 lbs. (approx. 20,900 kg)
Gear Ratios vs. Turns Per Inch: Low Gear = 33.8, High Gear = 2.5
