HOLLAND PH-760

The HOLLAND PH-760 Swivel Mount Pintle Hook features a split flange mounting design for heavy-duty construction, on/off-road towing applications where a significant amount of articulation is required.

Technical data





Max. Vertical Load: 9,800 lbs. (4,440 kg)
Max. Gross Trailer Weight: 49,000 lbs. (22,230 kg)
Drawbar Eye Dimensions: 3” I.D. with 1.25” - 1.63” diameter section
Weight: 36 lbs. (16.3 kg)



Product information

The HOLLAND PH-760 Pintle Hook is designed for heavy-duty construction, on/off-road towing applications where a significant amount of articulation is required. For severe off-road applications, reduce the above maximum capacities by 25% and use a rigid-mount drawbar.

The PH-760 Pintle Hook features:

  • Heat treated body and latch for increased strength
  • Split-flanges allow for a maximum .75” mounting plate
  • Front and rear flanges include grease fittings for lubrication
  • Latch pivot bolt with grease fitting for lubrication
  • Black Armour Corrosion Protection

Recommended use

Technologies

Black Armour® Corrosion Protection Learn more
Black Armour® Corrosion Protection Learn more

Literature

Document Thumbnail
HOLLAND Coupling Products Selection Guide
PDF / 29.17 MB
Document Thumbnail
SAF-HOLLAND Black Armour Sales Brochure
PDF / 792.31 KB
Document Thumbnail
PH-760 Specifications
PDF / 286.69 KB
