SAF CBXAN23 Aero Beam

The SAF CBXAN23 AeroBeam Top Mount Fixed Frame Air Suspension equipped with P89 Disc Brakes is the industry’s lightest weight system for vocational specialty, tank and platform trailers.

Technical data





Capacity: 23,000 lbs. (10.4 t)
Ride Heights: 14” / 15” / 16” / 17”
Standard Axle Track: 71.5” (optional 77.5” / 81.5” / 83.5”)



Product information

The SAF CBXAN23 AeroBeam Top Mount Fixed Frame Air Suspension delivers durability and proven performance, all in a lightweight system with multiple frame bracket mounting options.

The CBXAN23 Top Mount Fixed Air Suspension features:

  • Swing Align™ for fast and accurate axle alignment
  • Multi-functional pivot bushing with exterior void design
  • Optional P89™ or P89 Plus™ Air Disc Brakes
  • Optional SC5 Dressed Drum Wheel End package with 5-Year Warranty
  • Optional Tire Pilot Plus™ Tire Inflation System
  • Optional PosiLift™ lift axle system
  • 5.75”  diameter robust round axle
  • Black Armour® Corrosion Protection

Recommended use

Technologies

SwingAlign Learn more
P89 Series Air Disc Brakes Learn more
SC5 Dressed Drum Brake Wheel Ends Learn more
TIRE PILOT Plus Learn more
Black Armour® Corrosion Protection Learn more
SwingAlign Learn more
P89 Series Air Disc Brakes Learn more
SC5 Dressed Drum Brake Wheel Ends Learn more
TIRE PILOT Plus Learn more
Black Armour® Corrosion Protection Learn more

Literature

Document Thumbnail
SAF CBXA AeroBeam Fixed Frame Suspension Parts Manual
PDF / 2.58 MB
Document Thumbnail
SAF Air Disc Brake Service Parts Manual
PDF / 3.49 MB
Document Thumbnail
SAF-HOLLAND Truck & Trailer Suspension Original Parts Catalog
PDF / 88.74 MB
Document Thumbnail
Gabriel 2017 Parts Manual for Truck, Trailer and Bus Shocks
PDF / 6.59 MB
Document Thumbnail
Aftermarket Gabriel Shock Absorber Cross Reference document
PDF / 2.64 MB
