SAF MODUL with Drum Brake

The SAF MODUL drum braked offers an individual versatility of air suspension series in combination with all available drum braked axle versions.
Due to the numerous combination options, the optimum suspension system can be found for every transport task.


Technical data





Axle load: 7 - 14 t
Track width: 1830 – 2140 mm (depending on the axle version)
Brake: 17.5 / 19.5 / 22.5 "
Offset: Offset 0 / twin tires
Tire configuration: single and twin



Product information

The drum braked SAF MODUL offers individual solutions for economical transport services.

The main features are:

  • Air spring series: U, M, MT, O, EO, HU, AR421 and AR421H
  • Nominal ride height ranges: 170 to 600 mm
  • Articulation: 180 - 420 mm
  • Axle versions: 7, 9, 10, 11, 12 and 14 t
  • Provided tires: 17.5" (twin), 19.5" and 22.5" (single and twin)
  • Optional: SAF Lifting devices in different versions
  • Optional: SAF Bolt-on support brackets, aluminum and stainless-steel support brackets
  • Optional: SAF TIRE PILOT
  • Further options available

Recommended use

Technologies

MODUL-Technology Learn more
Compact Wheel Bearing Technology Learn more
SNK Brake Technology Learn more
SAF TIRE PILOT Technology Learn more
NFC-Technology Learn more
SAF TIRE PILOT I.Q. Technology Learn more
MODUL-Technology Learn more
Compact Wheel Bearing Technology Learn more
SNK Brake Technology Learn more
SAF TIRE PILOT Technology Learn more
NFC-Technology Learn more
SAF TIRE PILOT I.Q. Technology Learn more

Literature

Document Thumbnail
Nachrüstkit NFC Radkappe / Retrofit-Kit NFC Hubcap
PDF / 3.37 MB
Document Thumbnail
Repair kits for disc brakes, drum brakes & tools
PDF / 31.81 MB
Document Thumbnail
Toolbox Hub Puller
PDF / 2.29 MB
Document Thumbnail
Product Information - Lubricants
PDF / 56.71 KB
Document Thumbnail
Repair Kit - Wheel Hubs - 3 434 3019 00
PDF / 512.58 KB
