V.ORLANDI E525

The V.ORLANDI E525 series is a 50mm automatic drawbar coupling, which is designed for steering drawbar trailers and central axle trailers. This coupling series is homologated according to ECE standard, is easy to handle and can be maintained very fast and is cost efficient. All E525 couplings can be equipped with various sensor and remote options.

Product inquiry

Product information

The V.ORLANDI E525 series is composed by a rigid coupling, which allows a ± 105° steering angle and ± 20° vertical oscillation of the drawbar eye.

The main features consist of the following:

The E525 coupling stands out for ease weight and dimension in comparison to its competitors, it weighs less than 43 kg and has total length of 443 mm.
The pin can be opened at any angle between the truck and the trailer This series can be used for a wide range of application and for several markets.
It offers an automatic closing and manual opening mechanism.
This series is homologated acc. to ECE-R55 standard as class “C50-X”and can be equipped with manual or pneumatic remote opening system as well as several sensor indicators.
For special applications, a steel bell mouth is available.
Wear plate available as steel or optional as reinforced plastic version
The opening lever can be ordered mounted either upwards or downwards.

Technical data

Flange size	160x100 mm
D-Value	130 - 200 kN
DC-Value	83 – 135 kN
S-Load (Mass load)	1000 – 2500 kg
V-Value	29 – 75 kN
Weight	43 kg
Homologation	ECE R55 (Class C50-X)
Drawbar eye standard	DIN 74053; ECE R55 (Class D)
