V.ORLANDI OC40W

The V.ORLANDI OC40W series is a Ø 40 mm weldable drawbar eye, which is designed for steered drawbar trailers and central axle trailers. This drawbar eye is homologated according to ADR & ECE R55 standard.

Product information

The V.ORLANDI OC40W drawbar eye series allows at least 90° steering angle and ± 20° vertical oscillation if coupled with a DIN 74051 standard coupling.

The main features consist of the following:

  • Homologated according to ADR & ECE-R55 standard as class “S” in accordance with DIN 74054

  • Forged drawbar eye, strong and durable without risk of cracks and defects in the material

  • Long service life wear bushings, easily replaceable if required

  • This drawbar eye can be mounted on the trailer by welding

Technical data
Flange size: -
D-Value: 125 kN
DC-Value: 60 - 66 kN
S-Load (Mass load): 900 - 1000 kg
V-Value: 20 kN
Weight: 7.5 – 8 kg
Homologation: CRN 50511; ECE R55 (Class S)
Drawbar eye standard: DIN 74054; ECE R55 (Class S)
Literature
View all
Document Thumbnail
Technical Bullettin - OC40W04
PDF / 418.89 KB
