V.ORLANDI SHD

The V.ORLANDI SHD series is 40 ton heavy duty fifth wheel slider, which can be combined with 2” or with 3.5” fifth wheels. It is made of steel and homologated according to ECE R55 standard and are optimally adapted for specific heavy-duty applications.

Technical data





Stroke: Starting from 630 mm (pitch 105 mm)
D-Value: 260 kN
Fifth wheel load: 40,000 kg
Weight: 313 - 349 kg (stroke 630 mm)
Homologation: ECE R55 (Class J)



Product information

All V.ORLANDI SHD heavy duty fifth wheels sliders are particularly durable and offer through many options the maximum economy in the daily transport business. They can be equipped with a pneumatic remote kit.

The main features or the V.ORLANDI SHD series are:

  • Easy to service due to simple safe wear adjustment and low maintenance bearings

  • Suitable for a wide range of fifth wheel 2” or 3.5”

  • Suitable for a wide range of chassis width

  • Play adjustment device to increase driving comfort

  • Endless length

  • Easy to dismount to allow quick replacement of another preassembled fifth wheel

  • Optional pneumatic remote kit opening
