HOLLAND SDS Kompensator®

The HOLLAND Severe-Duty Slider (SDS) Kompensator® System is used for operating on rough or uneven terrain. The unique Kompensator® cradle design provides front-to-rear and side-to-side top plate oscillation, and is ideal for hauling trailers with high center of gravity loads such as tank trailers.

Technical data





Maximum Vertical Load up to 70,000 lbs. (32,000 kg)
Maximum Drawbar Pull up to 200,000 lbs. (91,000 kg)



Product information

The HOLLAND SDS Kompensator® Fifth Wheel Mounting System provides side-to-side oscillation, relieving the twisting force between the tractor and trailer. Use with the FW33, FW35 or the FW70 top plate for moderate or severe-duty applications.

The SDS Kompensator® Fifth Wheel Mounting System features:

  • Inboard or outboard mounting systems with Kompensator®
  • Multiple slider travels for weight distribution and swing clearance
  • Visual plunger lock indicators
  • 13” mounting height models only
  • 200k maximum drawbar pull capacity
  • In-cab air slide release control

Technologies

KOMPENSATOR® Mounting System Learn more
KOMPENSATOR® Mounting System Learn more
