HOLLAND SDS No-Tilt™

The HOLLAND Severe-Duty Slider (SDS) No-Tilt mounting system converts a standard articulating fifth wheel to a rigid “no-tilt” fifth wheel. SDS No-Tilt is required for higher load capacity hauling applications that require an articulating upper coupler such as a frameless dump trailer.

Product information

The HOLLAND SDS No-Tilt Mounting System provides a stable surface for frameless dump trailer applications. Use with the FW70 No-Tilt Top Plate for moderate or severe-duty applications.

The SDS No-Tilt Fifth Wheel Mounting System features:

Inboard or outboard mounting systems with No-Tilt slider brackets
Multiple slider travels for weight distribution and swing clearance
Visual plunger lock indicators
9” mounting bracket height models only
200k maximum drawbar pull capacity
In-cab air slide release control

Technical data

Maximum Vertical Load	up to 70,000 lbs. (32,000 kg)
Maximum Drawbar Pull	up to 200,000 lbs. (91,000 kg

Technologies

No-Tilt® Mounting System

Literature

View all

HOLLAND Sliding Fifth Wheels Air Line Kit Instructions

PDF / 231.89 KB
