NEWAY ADZ

The NEWAY ADZ Drive Axle Air-Ride Suspension for transit bus, motorcoach and motorhome applications provides maximum durability in demanding operational environments.

Technical data





Capacity per Axle: 23,000 lbs. / 26,000 lbs. (10,433 / 11,793 kg)
Ride Heights: 8.50 - 15”



Product information

The NEWAY ADZ Air-Ride Suspension is a non-torque reactive parallelogram design that is ideal for bus applications where a high center of gravity is present for superior roll-stability.

The ADZ Air-Ride Suspension features:

  • One piece lower control assembly

  • Wide spaced cast steel trailing arms for stability

  • EZ-Align non-welded alignment

  • Multiple configuration options available

  • Linear roll stability for high CG applications

  • Drive line friendly non-torque reactive parallelogram design

  • Black Armour Corrosion Protection

Recommended use

Technologies

Black Armour® Corrosion Protection Learn more
Black Armour® Corrosion Protection Learn more

Literature

Truck and Trailer Suspensions Parts Manual
PDF / 88.74 MB
Important Information - NEWAY ADZ Suspension Shock Absorber Upgrade
PDF / 463.25 KB
