HOLLAND MARK V™

The HOLLAND MARK V Landing Gear is the industry leader for capacity strength, cranking speed, and unmatched durability for exceeding the demands of any landing gear trailer application.

Technical data





Lift capacity:  62,500 lbs. (approx. 34,700 kg) at 100 ft.-lbs. (135 Nm) input torque
Ultimate load capacity: 200,000 lbs. (approx. 90,700 kg)
Side-Load Capacity: 32,000 lbs. (approx. 14,500 kg)
Gear Ratios vs. Turns Per Inch: Low Gear = 33.8, High Gear = 2.5



Product information

The HOLLAND MARK V Landing Gear sets the standard for lift and load capacity, cranking speed, durability and ease of lift. Widest range of travel lengths offered with multiple foot configurations.

The MARK V Landing Gear features:

  • Large, robust 5 1/8” square upper leg

  • Superior 32,000 lb. (approx. 14,500 kg) side-load capacity

  • Fastest to the ground with 2.5 turns per inch

  • Shifts easily in cold weather

  • High-strength ductile iron gears

  • Black Armour® Corrosion Protection

  • Optional Removable Cushion Foot (RCF)

  • Standard 5-Year Warranty and Optional 10-Year NoLube™ Extended Guarantee

  • Large 1 5/8” diameter double lead elevating screw

  • Premium Gearbox Grease service rated for -65ºF (-54°C) to 225ºF (107°C)

Recommended use

Technologies

NoLube™ Learn more
Black Armour® Corrosion Protection Learn more
NoLube™ Learn more
Black Armour® Corrosion Protection Learn more
