The HOLLAND PH-30SB41 Swivel-Mount Pintle Hook features an under-mount design with spring shock absorption, and is approved for on/off-road towing applications.

Technical data



Max. Vertical Load: 6,000 lbs. (2,720 kg)
Max. Gross Trailer Weight: 30,000 lbs. (13,610 kg)
Drawbar Eye Dimensions: 2.38” - 3” I.D. with 1.25” - 1.63” diameter section
Weight: 38 lbs. (14.5 kg)


Product information

The HOLLAND PH-30SB41 Medium Duty Pintle Hook with under-mount attachment is designed for on/off-road towing applications. For off-road applications, reduce the above maximum capacities by 25% and use with a rigid-mount drawbar.

The PH-30SB41 Pintle Hook features:

  • FastLatch™
  • Heat treated body and latch for increased strength
  • Grease fitting for easy lubrication
  • Steel coil spring provides shock absorption
  • Integrated housing design for cross-bracing attachment
  • Available with a tethered lock pin (PH-30SB51)
  • Black Armour Corrosion Protection


FastLatch™ Learn more
Black Armour® Corrosion Protection Learn more
FastLatch™ Learn more
Black Armour® Corrosion Protection Learn more


Document Thumbnail
HOLLAND Coupling Products Selection Guide
PDF / 29.17 MB
Document Thumbnail
SAF-HOLLAND Black Armour Sales Brochure
PDF / 792.31 KB
Document Thumbnail
PH-30SB41 Swivel Type Pintle Hook Specifications
PDF / 459.28 KB
