SAF CBXAS Aero Beam Series

The SAF CBXAS AeroBeam Top Mount Fixed Frame Air Suspension Series delivers a versatile range of lightweight, durable models for on/off-highway, vocational specialty and heavy haul trailer applications.

Product information

The SAF CBXAS AeroBeam Series offers 23K, 25K and 30K capacity models for vocational specialty and multi-axle trailers. The lighter weight, more durable cast steel trailing arm features an integral shock absorber location for improved performance and undercarriage clearance.

The CBXAS AeroBeam Series features:

  • Swing Align™ for fast and accurate axle alignment
  • Multi-functional pivot bushing with exterior void design
  • Optional P89™ or P89 Plus™ Air Disc Brakes
  • Optional SC5 Dressed Drum Wheel End package with 5-Year Warranty
  • Optional Tire Pilot Plus™ Tire Inflation System
  • Optional PosiLift™ and CBL (center bag lift) lift axle systems
  • 5.75” diameter robust round axle
  • Black Armour® Corrosion Protection
Technical data
Capacity: 23,000 / 25,000 / 30,000 lbs. (10.4 / 11.3 / 13.6 t)
Ride Heights: 14” / 15” / 16” / 17” / 18” / 19”
Standard Axle Track: 71.5” (optional 77.5” / 81.5” / 83.5”)
