Technical data
| Capacity: | 23,000 and 25,000 lbs. (10.4 and 11.3 t) |
| Ride Heights: | 6” / 7” / 8” / 9” / 10” / 12” |
| Standard Axle Track: | 71.5” (optional 75.5” / 77.5” / 81.5” / 83.5”) |
Product information
The SAF CBXu Underslung Fixed Frame Air Suspension delivers durability in a lightweight system for low-profile on/off-highway trailer applications with multiple configurations.
The CBXu Underslung Fixed Air Suspension features:
- SwingAlign™ for fast and accurate axle alignment
- Multi-functional pivot bushing with exterior void design
- Optional P89™ or P89 Plus™ Air Disc Brakes
- Optional SC5 Dressed Drum Wheel End package with 5-Year Warranty
- 25/30k capacity model available (rated for 30k at creep speed)
- Optional Tire Pilot Plus™ Tire Inflation System
- Optional 5” axle for smaller brake configurations
- CBXy Yoke Mount model available for lowboy trailer applications
- Black Armour® Corrosion Protection
