Technical data
| Max. Lift @80 psi: | 390 lbs. (177 kg) |
| Max. Drawbar Pull: | 15,000 lbs. (6,800 kg) |
| Coupling Pin: | 1.75” diameter |
| Weight: | 136 - 173 lbs. (61.7 - 78.5 kg) depending on model |
Product information
The Dolly Master™ is an in-cab operated, tractor nose-mounted pin coupling device, featuring a double-acting air cylinder that moves a sliding pin up and down for easy spotting of converter dollies. Model TF-675 lifts from bumper height, and models TF-675-1/3A lift from ground height.
The Dolly Master™ features:
-
Welded steel frame
-
Vertical pin slide with integral guide ramps
-
Optional lock-out cylinder model (TF-675-1)
-
Optional bolt-on model with lock-out sensor (TF-675-3A)
-
Black Armour Corrosion Protection
