SAF CBXAS AeroBeam™ Series

The SAF CBXAS AeroBeam™ Top Mount Fixed Frame Air Suspension Series delivers a versatile range of lightweight, durable models for on/off-highway, vocational specialty and heavy haul trailer applications.

Product inquiry

Product information

The SAF CBXAS AeroBeam™ Series offers 23K, 25K and 30K capacity models for vocational specialty and multi-axle trailers. The lighter weight, more durable cast steel trailing arm features an integral shock absorber location for improved performance and undercarriage clearance.

The CBXAS AeroBeam™ Series features:

SwingAlign™ for Fast and Accurate Axle Alignment
Multi-Functional Pivot Bushing with Exterior Void Design
Optional P89™ PSP7 or P89 Plus™ Air Disc Brakes*
Optional SC5 Dressed Drum Wheel End Package with 5-Year Warranty
Optional Tire Pilot Plus™ Tire Inflation System
Optional PosiLift™ or CBL (Center Bag Lift) Lift Axle Systems
5.75” Diameter Robust Round Axle
16½”x 7” Extended Service Brake Linings and Heavy-Duty S-Cams for both Taper and Parallel Spindles
Black Armour® Corrosion Protection
Featuring Haldex Calipers and Actuators

*Suspension capacity shown. Axle and brakes rated independently.

Technical data

Suspension Capacities:	23,000 / 25,000 / 30,000 lbs. (10.4 / 11.3 / 13.6 t)
Ride Heights:	14” / 15” / 16” / 17”
Standard Axle Track:	71.5” (optional 77.5” / 83.5”)
