SAF ULX40 ULTRALITE®

The SAF ULX40 UltraLite Mechanical Suspension and Axle System is a proven original Binkley design and is the lightest weight tandem sliding suspension system available for dry van and reefer trailer applications.

Product information

The SAF ULX40 UltraLite Mechanical Sliding Axle System with spring-ride technology is a proven performer and the choice for many on-highway fleets for its low maintenance operation requirements.

The ULX40 UltraLite Mechanical Sliding Suspension features:

Qwik Release Pin Pull System with 20% less pulling effort
Optional P89™ or P89 Plus™ Air Disc Brakes
Optional SC5 Dressed Drum Wheel End package with 5-Year Warranty
Optional Air operated pin pull release for easy slider sub-frame repositioning
Optional Tire Pilot Plus™ Tire Inflation System
Optional composite springs for enhanced ride performance and weight savings
Slider sub-frame with open style G-rails for strength and anti-corrosion
Hardened steel wear pads to reduce hanger wear
5.75” robust round axle
Black Armour® Corrosion Protection

Technical data

Capacity:	40,000 lbs. (18.1 t)
Ride Heights:	13.25” - 18”
Standard Slider Width:	48” (optional 42” and 54”)
Standard Axle Track:	77.5” (optional 71.5” and 83.5”)
