Assali Stefen TM - FT Axle Range

The Assali Stefen TM - FT is available for 17.5", 19.5" and 22.5" wheels.

The axles can be supplied in command and self-steering axle versions.

Product information

Features and benefits

Off-set flange hub option available in the drum version and for 19,5’’ and 22,5’’ wheels
Option of oil filled hubs
The most tested and well-known axle on the market
Also available in command and self-steering axle versions

Technical data

Loading capacity:	up to 13,5 ton
Wheels:	17,5”, 19,5” o 22,5”, single or twin
Brakes:	Disc Brakes: R (378 mm, 19,5” wheel only) K (378 mm, 19,5” wheel only) Drum Brakes: Q+ (420 x 180 mm) Z/ZS (420 x 220 mm) B/BH (350 x 200 mm) AC/AS (310 x 190 mm) S/SC (310 x 160 mm)
