SAF Hercules

The SAF Hercules is the 24 t standard landing gear for the most common vehicle applications.

Technical data





Lift capacity:  24,000 kg
Static load capacity: 50,000 kg
Lift in low gear: 1 mm per turn
Lift in high gear: 12 mm per turn
Standard foot: compensator foot
Mounting height / lift: 655 / 350 mm
  705 / 400 mm
  750 / 410 mm
  800 / 460 mm
  850 / 510 mm



Product information

The SAF Hercules has a particularly optimized mounting height / lift ratio for the low mounting heights, thus this series can be used in low Mega semi-trailers  up to high semi-trailer tippers.

 The main features are:

  • Continuous 10 hole 3D back plate

  • Various foot options

  • Wide range of accessories

  • Powder coating with high quality pretreatment

  • Web-based spare part identification by QR code

  • 3 years maintenance free

Recommended use

Literature

Wichtige Info 96 – Sales
PDF / 87.70 KB
Important Info 96 – Sales
PDF / 94.70 KB
Product Overview: Spare part shopping per QR-Code
PDF / 636.96 KB
Product Overview: Spare part shopping per QR-Code
PDF / 444.44 KB
Product Overview: Spare part shopping per QR-Code
PDF / 636.96 KB
Produktübersicht: SAF HERCULES · SAF HERCULES COMPACT · SAF Fallstütze · SAF Schwenkstütze
PDF / 1.24 MB
Product Overview: SAF HERCULES · SAF HERCULES COMPACT · SAF Drop Leg · SAF Swivel Landing Gear
PDF / 1.24 MB
Betriebsanleitung - SAF Hercules · SAF Fallstütze
PDF / 2.28 MB
Owner´s Manual - SAF Hercules / SAF drop leg
PDF / 2.26 MB
Konstruktionshandbuch - SAF Hercules
PDF / 3.24 MB
Produktübersicht: SAF Hercules
PDF / 719.86 KB
CATALOGUE: Original SAF-HOLLAND Spare Parts & Components
PDF / 11.61 MB
Price List: Spare Parts
XLS / 718.00 KB
