V.ORLANDI OC68F

The V.ORLANDI OC68F is a Ø 68 mm flanged pivoting drawbar eye, which is designed for steering drawbar trailers and central axle trailers. This drawbar eye is homologated according to ECE R55 standard and comes always with the fasteners.

Technical data





Flange size: Ø 160 mm
D-Value: 200 kN
DC-Value: 140 kN
S-Load (Mass load): 1000 kg
V-Value: 90 kN
Weight: 24 kg
Homologation: ECE R55 (Class S)
Drawbar eye standard: BNA NF R41-102; ECE R55 (Class S)



Product information

The V.ORLANDI OC68F allows at least ± 90° steering angle and ± 20° vertical oscillation if coupled with a BNA NF R41-101 standard coupling.

The main features consist of the following:

  • Homologated according to ECE-R55 standard as class “S” in accordance with BNA NF R41-102

  • Forged drawbar eye, strong and durable without risk of cracks and defects in the material

  • Long service life wear bushings, easily replaceable if required

  • This drawbar eye can be mounted on the trailer by using screws
