V.ORLANDI DE70

The V.ORLANDI DE70 is a manual mixed Pin & Ball coupling, which is designed for steering drawbar trailers and central axle trailers up to 3.5 tons.

This coupling is homologated according to ECE R55 standard and is easy to handle, can be maintained very fast and is cost efficient.

Technical data





Flange size 90 mm
D-Value 23 kN
DC-Value 23 kN
S-Load (Mass load) 150 kg
V-Value -
Weight 3.9 kg
Homologation ECE R55 (class A50X / S)
Drawbar eye standard DIN 74054; DIN 74053; VG 74059; CUNA 438-40
ECE R55 (class B50); ECE R55 (class S)



Product information

The V.ORLANDI DE70 is a manual mixed coupling with a 50mm ball hitch and a 29mm pin coupling, which is designed for small steering drawbar trailers and central axle trailers up to 3.5 tons.

The main features consist of the following:

  • It can be used with a wide range of drawbar eyes.
  • The DE70 is homologated according to ECE R55 standard as “class A50X” for the pin execution and “class S” for the ball execution.

Literature

Technical Data - DE70
PDF / 86.04 KB
