V.ORLANDI FDH

The V.ORLANDI FDH series consist of 2” 18 ton dual fifth wheels, made of spheroidal graphite cast iron. They are homologated in accordance with ECE R55 standard and optimally adapted for dual use of low deck tractors coupling mega trailers or conventional semitrailers. They are available as a standard or as a NoLube versions.

Product inquiry

Product information

All V.ORLANDI FDH dual fifth wheels are particularly durable and offer through many options the maximum economy in the daily transport business. This fifth wheel series has a tilt angle of ± 12 (upper position) +8° -6° (lower position). There are many hole patterns available for several OEMs.

The main features of the V.ORLANDI FDH series are:

Easy to service due to simple safe wear adjustment and low maintenance bearings
Reliable and robust height-adjustable by means of air pressure
Higher imposed load value
Suitable for steering wedge
Optional NoLUBE version: grease-free due to sliding plates
Pneumatic basement version available on request
Different hole patterns available

Technical data

Lock size:	2”
Overall heights:	167 – 267 / 167 – 317 / 167 - 367 mm
D-Value:	120 kN
Fifth wheel load:	18,000 kg
Weight:	341 - 346 kg
Hole pattern:	Undrilled / Daimler / Iveco / Scania / Volvo / Man / Renault / DAF / Mercedes new Actros
Homologation:	ECE R55 (Class S)
