V.ORLANDI RP59

The V.ORLANDI RP59 series consists of 2” 24 ton fifth wheels made of spheroidal graphite cast iron. They are homologated in accordance with ECE R55 standard and are optimally adapted for standard long-distance transport.

Technical data





Lock size: 2”
Overall heights: 190 / 250 mm
D-Value: 170 kN
Fifth wheel load: 24,000 kg
Weight: 200 - 215 kg
Homologation: ECE R55 (Class G50)



Product information

All fifth wheels of the V.ORLANDI RP59 series are particularly durable and offer through many options the maximum economy in the daily transport business. This fifth wheel type has a tilt angle of + 12° /-15°, or ± 15° (depends on the assembly height of the fifth wheel).  It cannot be mounted directly on the chassis, but requires a mounting plate attached to the vehicle.

The main features of the V.ORLANDI RP59 are:

  • Easy to service due to simple safe wear adjustment and low maintenance bearings

  • Fifth wheel on rubber mounting

  • Convertible 2” – 3.5”

  • Suitable for steering wedge
