HOLLAND PH-30SA41

The HOLLAND PH-30SA41 Swivel Mount Pintle Hook features a split flange mounting design with spring shock absorption, and is approved for on/off road towing applications.

Product information

The HOLLAND PH-30SA41 Swivel Mount Pintle Hook with spring shock absorption is designed for on/off road towing applications. For off-road applications, reduce the above maximum capacities by 25% and use with a rigid-mount drawbar.

The PH-30SA41 Pintle Hook features:

FastLatch™
Heat treated body and latch for increased strength
Steel coil spring provides shock absorption
Split-flanges allow for a maximum 5/8” mounting plate
Available with a tethered lock pin (PH-30SA51)
Black Armour Corrosion Protection

Technical data

Max. Vertical Load:	6,000 lbs. (2,720 kg)
Max. Gross Trailer Weight:	30,000 lbs. (13,610 kg)
Drawbar Eye Dimensions:	2.38” - 3” I.D. with 1.25” - 1.63” diameter section
Weight:	32 lbs. (14.5 kg)
