SAF TRAKr: Electric recuperation - power generation while driving.
During braking or in overrun phases, the centrally located high-voltage generator unit of the SAF TRAKr converts the kinetic energy of the vehicle into electrical energy.
The main features of the SAF TRAKr are:
- Standardized system: identical in construction to standard axles
- Retrofitting: Retrofitting possible
- Independent from trailer manufacturer
- Standard wear parts for simplified spare parts supply
- Simple maintenance: Maintenance of tires, wheel heads and brakes without dismantling the system
- Reduction of background noise while driving
- More efficiency through reduced loading and idle times
- Driver-friendly and easy to operate
Recommended use:
- Cooler
- Silo
- Moving Floor
- Lifting platform
- Transportable e-forklift
Technical data
| Axle load: | 9 t INTRA , 10 t MODUL (in progress) |
| Track width: | 2040 / 2090 / 2140 mm |
| Brakes: | 19.5” / 22.5” |
| Offset: | Offset 120 / single |
| Tyre configuration: | e.g. 385/65R22.5" / e.g. 425/55R19.5" |
| Gearbox: | 1-speed with differential Gear ratio i=1:14 |
| E-machine: | Liquid-cooled (available): - liquid-cooled permanent magnet machine (PSM) - max. power: 20 kW peak power*, 16 kW continuous power* *system-related |
| Air-cooled (in progress): - air-cooled switchable reluctance machine (SRM): - max. power: 20 kW peak power*, 16 kW continuous power* *system-related, at 20°C ambient temperature |
Interested? Get in contact.
