V.ORLANDI OC70W-HD

The V.ORLANDI OC70W-HD is a Ø 70 mm weldable drawbar eye suitable for heavy duty applications, which is designed for steered drawbar trailers. This drawbar eye is homologated according to ADR & ECE R55 standard.

Technical data





Flange size:
D-Value: 800 kN
DC-Value:
S-Load (Mass load): 500 to. (total trailer weight)
V-Value:
Weight: 46.4 kg
Homologation: CRN 46899; ECE R55 (Class S)
Drawbar eye standard: CUNA 438-55; ECE R55 (Class S)



Product information

The V.ORLANDI OC70W-HD drawbar eye allows ± 95° steering angle and ± 22° vertical oscillation if coupled with a CUNA 138-55 cl. VIII standard coupling.

The main features consist of the following:

  • Homologated according to ADR & ECE-R55 standard as class “S” in accordance with CUNA 438-55 cl. VIII

  • Forged drawbar eye, strong and durable without risk of cracks and defects in the material

  • Long service life wear bushings, easily replaceable if required

  • This drawbar eye can be mounted on the trailer by welding

Literature

Technical Data - OC70
PDF / 86.52 KB
Installation and Operating Instructions - V.ORLANDI OC Series
PDF / 3.13 MB
Technical Bulletin
PDF / 370.46 KB
