Product information
The HOLLAND DB-100FQ1 Rigid-Mount Bolt-On Drawbar is used on trailers, semi-double trailers. Approved for on/off-road towing applications. For severe off-road applications, reduce published capacities by 25% and use with swivel-mount coupling.
The DB-100FQ1 Drawbar features:
-
Forged, heat treated one-piece steel
-
Eye I.D. induction hardened for wear resistance
-
Tested in accordance with ADR and ECE
-
Black Armour Corrosion Protection
Technical data
| Max. Vertical Load: | 20,000 lbs. (9,072 kg) |
| Max. Gross Trailer Weight: | 100,000 lbs. (45,360 kg) |
| Drawbar Eye Dimensions: | 3” (76.2 mm) I.D. with 1.63” (41.4 mm) diameter section |
| ADR D-Value Rating: | 180 kN (CRN 47475) |
| Weight: | 19 lbs. (8.6 kg) |
