HOLLAND G36

The weight-optimized 20 t fifth wheel HOLLAND G36 made of spheroidal graphite cast iron is optimally adapted for use in standard long-distance transport.

Product information

All fifth wheels of the HOLLAND G36 series are particularly durable and offer with many options the maximum economy in the daily transport business.

The main features are:

  • Convenient single hand operation with automatic safety lock

  • Easy to service due to simple safe wear adjustment and low-maintenance bearings

  • Approved for forced steering

  • Direct or angle bracket mounting possible

  • Optional: connection of a long-term lubricant dispenser

  • Optional with RECOLUBE: automatic central lubrication for MAN tractors

  • Optional with RECOSS: safety sensor system - available for Mercedes-Benz, Renault and Volvo tractors ex works

  • Optional: low-maintenance due to wear-optimized sliding plate

  • Optional NoLUBE version: grease-free due to sliding plates, as well as hardened lock piece and wear ring

Technical data
Lock size: 2"
Imposed Load: 20,000 kg
Overall heights: 128 (+12mm MP) / 150 / 185 / 225 / 250 mm
D-Value:  200 kN
ECE Test no.: ADR & E1 55R-01 0218
