HOLLAND PH-775-01552

The HOLLAND PH-775-01552 Swivel Mount Pintle Hook and is designed for heavy-duty on/off-road construction towing applications where a significant amount of coupling articulation is required.

Product information

The HOLLAND PH-775-01552 Pintle Hook is designed for heavy-duty on/off-road construction applications where a significant amount of coupling articulation is required. For severe off-road applications, reduce the above maximum capacities by 25% and use a rigid-mount drawbar.

The PH-775-01552 Pintle Hook features:

Heat treated body and latch for increased strength
One-piece housing keeps contaminants out
Grease fittings for easy lubrication
Interchangeable with PH-995SH71 (not applicable for Australia)
Complies with ADR 62, CRN
Complies with NOM-035-SCT-2-2010 Safety Specifications/Test Methods (not applicable for Australia)
Black Armour Corrosion Protection

Technical data

Max. Vertical Load:	20,000 lbs. (9,070 kg)
Max. Gross Trailer Weight:	100,000 lbs. (45,360 kg)
D-Value rating:	D = 180 kN
Drawbar Eye Dimensions:	3” (76.2 mm) I.D. with 1.63” (41.4 mm) diameter section
Weight:	60 lbs. (27.2 kg)

Technologies

Black Armour® Corrosion Protection
