SAF Heavy Duty 12-16t

The SAF heavy duty axles are available in different versions from 12 t to 16 t.

The axles can be supplied with different spring seats, for mechanical suspension, air suspension and hydraulic suspension.

Product information

The SAF heavy duty axles are based on the proven SK brake technology and compact bearing technology, various wheel combinations and brake sizes can be combined as rigid and steered axles so that all axle combination needs can be met.

Technical data

Axle load:	12 - 16 t
Track width:	1800 - 2140 mm
Brakes:	Simplex S-cam brake Air disc brake
Wheel size - wheel connection - brake size:	17.5" TK 225/10L; 300x150; 300x200 19.5" TK 275/8L; TK 285.75/10L; 367x150; 367x180; 367x200 19.5" TK 275/8L; TK335/10l; 370x45 22.5" TK 335/10L; TK285.75/10L; 420x200 22.5" TK 335/10L; 430x45"
Tire Configuration:	Single / Twin Tire

Technologies

Compact Wheel Bearing Technology

INTEGRAL-Technology

PREMIUM COATED-Technology

SAF TIRE PILOT Technology

STEERING Technology

Hydraulic Drive Technology
