The YORK YTB 90 HD Cast Mechanical suspension is a product specifically developed for on & off road use in rough conditions.

Technical data



Axle load: 18 - 25 t (Pending on Road and Speed)
Suspension Axle Centers: 1300 / 1360 / 1550 mm
Spring Pack: 10 – 11 leaf
Spring Width: 90x16 - 20 mm
Suspension Hangers: Heavy Duty Casting; Equalizer fitted Vesconite or Bronze bushes
Right Height: 275 - 540 mm; Under / Overslung
Axle Clamp Group: ø 152 / 150 mm


Product information

The YORK YTB 90 HD Cast is suitable for arduous outback terrain, long haul driving in outback, as well as, mining, logging or wharf work and

offers the following:

  • Heavy-duty mechanical suspensions suitable for on road and off road conditions.
  • Mechanical Suspension – High strength cast hangers and equalizers components to suit high capacity mining applications
